chiwia . & | [| { 8 | anees / TECH TIPS Dixie Part Numbers: A-2082 (plus unlisted at this time) Applications: 2007 — 2008 Ford Explorer 4.0L 2007 — 2008 Mercury Mountaineer 4.0L 2009 Ford Mustang 4.0L Condition: The operator of the vehicle may complain of the drive belt squealing or chirping in the vicinity of the power steering pulley. Cause: A potential cause is an incorrect alternator bracket. Correction: Inspect all components driven by the accessory belt for wear or damage. Inspect the belt clearance on the idler pulley, there should be 2mm of clearance at the rear of the pulley, if not the alternator bracket may be incorrect or incorrectly (improperly seated or improperly torqued). Verify that the alternator and idler pulley are properly installed and torqued as defined in the manufacturer’s specifications. If the belt clearance is still incorrect replace the bracket with an updated one (dealer number 1L5Z- 10A313-BA). Replace the drive belt with an updated one (dealer number 5R3Z-8620-AA). REV: 20091221 Courtesy of Dixie Technical Department TSB_234.doc Dixie Tech Tips are intended for use by professional technicians, and are not for the general public. They are written to inform technicians of conditions that may exist or as a guide to aid in diagnosing and servicing a vehicle. All references to original equipment manufactures, vehicle manufactures and any other Trade Mark names are for the sole purpose of identifying the vehicle and or part that the Tech Tip applies to. This document is property of Dixie Electric Ltd. and is not to be copied or distributed with out written permission.
