XIE ) TECH TIPS Dixie Part Numbers: A-8669 A-8890 A-8930 A-8947 A-80043 Applications: 1997 Kia Sephia 1.8L 1997 — 1998 Mazda Protégé 1.5L 1999 — 2000 Mazda Miata/MX5 1.8L 1999 — 2001 Mazda Protégé 1.6L 1999 — 2003 Mazda Protégé 1.8L 2000 — 2001 Mazda MPV 2.5L 2002 — 2006 Mazda MPV 3.0L Condition: The vehicle’s charging system is not working properly even though the alternator has been replaced. Cause: This alternator has a P —D style regulator, or external driver. Correction: For this Dixie Tech Tip only topic of the P—D regulator will be covered. For the following topics refer to the appropriate Dixie Tech Tip: e Voltage Drop Testing — TSB-001 Alternator Trouble Shooting Guide — TSB-010 Alternator Installation Guide — TSB-011 Alternator Pulley Installation Guide — TSB-012 Why batteries can not be disconnected to test alternators — TSB-013 To properly test the alternator use a voltmeter only on the P terminal — never on the D terminal or the alternator will immediately fail. Never apply voltage to the D terminal or the alternator will be destroyed! This is a common mistake, as the plug looks identical to other plugs used on many other Mitsubishi manufactured alternators but with different terminals. Below are pictures of the resulting damage to the transistor in the alternator, the transistor has been blown apart. “| REV: 20090911 Courtesy of Dixie Technical Department TSB_844.doc Dixie Tech Tips are intended for use by professional technicians, and are not for the general public. They are written to inform technicians of conditions that may exist or as a guide to aid in diagnosing and servicing a vehicle. All references to original equipment manufactures, vehicle manufactures and any other Trade Mark names are for the sole purpose of identifying the vehicle and or part that the Tech Tip applies to. This document is property of Dixie Electric Ltd. and is not to be copied or distributed with out written permission.
